Description
Barrel roller bearings 203, main dimensions to DIN 635-1
FAG
20306-TVP-C3
Barrel roller bearing
⌀30 × 72 × 19 mm
od EUR 165.99z VAT
netto EUR 134.95 · cena detaliczna
This item is brought in to order (about 10 working days) and we sell it to business customers. Open a business account.
20306-TVP-C3—
EUR 165.99
To orderapprox. 10 days
Brought in to order — approx. 10 working days
Symbol (SKU)20306-TVP-C3#N1
EAN4012801286626
Wymiary⌀30 × 72 × 19 mm
Masa361 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
27 parametersIdentification
- Manufacturer
- FAG
- Type
- Barrel roller bearing
- Part number (SKU)
- 20306-TVP-C3#N1
- EAN
- 4012801286626
- Cage
- TVP
Dimensions
- Bore d
- 30 mm
- Outside diameter D
- 72 mm
- Width B
- 19 mm
- Mass
- 361 g
- Radial clearance
- C3 (Group 3)
Load ratings and operation
- Dynamic load rating C
- 48500 N
- Static load rating C₀
- 48500 N
- Limiting speed
- 8800 1/min
Full manufacturer specification14 parameters · expand
- Bore diameter outer ring
- 60.7 mm
- Bore type
- Z
- Cage
- TVP
- Fatigue load limit, radial
- 4350.0 N
- Maximum diameter of housing shoulder
- 65.0 mm
- Maximum recess radius
- 1.0 mm
- Minimum chamfer dimension
- 1.1 mm
- Minimum diameter shaft shoulder
- 37.0 mm
- Operating temperature max.
- 120.0 °C
- Operating temperature min.
- -30.0 °C
- PFAS
- nein
- Radial internal clearance
- C3 (Group 3)
- REACH
- REACH conform
- RoHS
- RoHS compliant
