Description
Angular contact ball bearing 30..-B-2RS-TVH, double row, seals, plastic cage
INA
3001-2RS-C3
Angular contact ball bearing
⌀12 × 28 × 12 mm
od EUR 18.60z VAT
netto EUR 15.12 · cena detaliczna
EUR 23.74−22%
3001-2RS-C3—
EUR 23.74
EUR 18.60Cheaper in larger quantities
| from 10 pcs | EUR 18.91 | −2% |
| from 50 pcs | EUR 18.53 | −4% |
| from 250 pcs | EUR 18.33 | −5% |
In stock (34 pcs)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)3001-2RS-C3#N1
EAN4054365724558
Wymiary⌀12 × 28 × 12 mm
Masa33 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
35 parametersIdentification
- Manufacturer
- INA
- Type
- Angular contact ball bearing
- Part number (SKU)
- 3001-2RS-C3#N1
- EAN
- 4054365724558
- Cage
- TVH
- Tolerance class
- PN
Dimensions
- Bore d
- 12 mm
- Outside diameter D
- 28 mm
- Width B
- 12 mm
- Mass
- 33 g
Load ratings and operation
- Dynamic load rating C
- 6100 N
- Static load rating C₀
- 3700 N
- Limiting speed
- 15800 1/min
Full manufacturer specification22 parameters · expand
- Axial internal clearance
- C3
- Cage
- TVH
- Caliber diameter outer ring
- 23.16 mm
- Caliber diamter inner ring
- 16.4 mm
- Contact angle
- 25.0 °
- Design variant
- B
- Dimensional / heat stabilization
- SN
- Distance between the apexes of the pressure cones
- 13.5 mm
- Fatigue load limit, radial
- 193.0 N
- Lubricant
- GA13
- Maximum diameter of housing shoulder
- 26.0 mm
- Maximum fillet radius
- 0.3 mm
- Minimum chamfer dimension
- 0.3 mm
- Minimum diameter shaft shoulder
- 14.0 mm
- Operating temperature max.
- 100.0 °C
- Operating temperature min.
- -20.0 °C
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Shoulder diameter inner ring
- 17.6 mm
- Shoulder diameter outer ring
- 22.5 mm
- Type of Sealing
- 2RS
