Description
Locknuts KM, main dimensions to DIN 981
FAG
KM8
Locknut
od EUR 5.34z VAT
netto EUR 4.34 · cena detaliczna
EUR 6.27−15%
KM8—
EUR 6.27
EUR 5.34Cheaper in larger quantities
| from 10 pcs | EUR 5.00 | −2% |
| from 50 pcs | EUR 4.90 | −4% |
| from 100 pcs | EUR 4.90 | −4% |
Last few (18)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)KM8#N1
EAN4012801174381
Masa94 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
17 parametersIdentification
- Manufacturer
- FAG
- Type
- Locknut
- Part number (SKU)
- KM8#N1
- EAN
- 4012801174381
Dimensions
- Width B
- 9 mm
- Mass
- 94 g
Full manufacturer specification11 parameters · expand
- Axial load capacity, static
- 58000.0 N
- Chamfer angle
- 30.0 °
- Chamfer diameter
- 50.0 mm
- Fuse
- MB8
- Groove base distance
- 53.0 mm
- Outerside diameter
- 58.0 mm
- PFAS
- nein
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Thread
- M40x1,5
- Width retaining slot
- 6.0 mm
