Description
Tab washers MB, main dimensions to DIN 5406
FAG
MB38
Securing plate
⌀190 × 252 mm
od EUR 24.93z VAT
netto EUR 20.27 · cena detaliczna
EUR 33.25−25%
MB38—
EUR 33.25
EUR 24.93Cheaper in larger quantities
| from 10 pcs | EUR 26.49 | −2% |
| from 15 pcs | EUR 25.95 | −4% |
| from 50 pcs | EUR 25.95 | −4% |
Last few (10)dispatch within 24 h
Dispatched within 24 h from our own warehouse
Symbol (SKU)MB38#N1
EAN4012801315012
Wymiary⌀190 × 252 mm
Masa288 g
Buying for a company?
A business account gives net prices, quantity breaks, deferred payment and ordering from a list of designations.
Open a business account →Technical data
15 parametersIdentification
- Manufacturer
- FAG
- Type
- Securing plate
- Part number (SKU)
- MB38#N1
- EAN
- 4012801315012
Dimensions
- Bore d
- 190 mm
- Outside diameter D
- 252 mm
- Mass
- 288 g
Full manufacturer specification8 parameters · expand
- Counted quantity
- 100.0
- Distance lug
- 20.0 mm
- PFAS
- nein
- Plant diameter outside
- 214.0 mm
- REACH
- REACH conform
- RoHS
- RoHS compliant
- Thickness
- 2.5 mm
- Width lock washer tab
- 18.0 mm
